Industrial sludge dewatering
Placeholder project entry. Replace this description with the verified project scope, geology, slurry data and equipment configuration.
Microtunneling slurry dewatering
Bentonite / construction slurry
Microtunneling drive through mixed ground, with the separation plant on the shaft platform.
- Treatment capacity
- 90 m³/h
- Cake moisture
- 30 – 35 % dry solids
- Filter press model
- 2 × chamber press, 1000 × 1000 mm
Configuration data
- Country
- [PROJECT COUNTRY]
- Location
- [PROJECT LOCATION]
- Application
- Microtunneling slurry treatment
- Slurry type
- Bentonite / construction slurry
- Treatment capacity
- 90 m³/h
- Solids concentration
- 8 – 15 % by weight
- Filter press model
- 2 × chamber press, 1000 × 1000 mm
- Filter area
- 120 m² total
- Filtration pressure
- 0.6 – 1.6 MPa
- Cake moisture
- 30 – 35 % dry solids
- Filtrate recovery
- Returned to the slurry tank
- Equipment quantity
- 1 containerised plant
- Project date
- Reference configuration
Equipment configuration
| Screening | Vibrating screen, single deck with wash water |
|---|---|
| Desanding | Two-stage hydrocyclones · sand screw classifier |
| Conditioning | Automatic flocculant dosing station · in-line mixer |
| Dewatering | 2 × chamber filter press, 1000 × 1000 mm · 120 m² total |
| Support equipment | Duty/standby feed pumps · filtrate pump · PLC with HMI |
Process flow
The sequence as it runs on site.
- 01ScreeningRemove coarse solids before the slurry enters the separation circuit.
- 02DesandingRecover the sand fraction with hydrocyclones and a sand screw.
- 03ConditioningDose flocculant and mix so the fines can be filtered.
- 04Filter pressDewater the conditioned slurry in the filter press.
- 05Water recoveryReturn clear filtrate to the slurry circuit.
Design figures
-
Design throughput
90 m³/h
-
Target cake
30 – 35 % dry solids
-
Filtrate reuse
Returned to the slurry tank
-
Plant arrangement
Containerised, on the shaft platform
